Inversor híbrido de fase dividida SANDISOLAR de 12 kW
Modelo: SD-48120WP-US
The SANDISOLAR 12kW Hybrid Inverter is a premium all-in-one energy storage solution designed for North American 120V/240V split-phase systems. It delivers 12,000W continuous output with 125% EPS peak capacity and supports heavy-duty applications with up to 6HP motor capability. Equipped with dual MPPTs (27A+27A), it supports up to 150% PV oversizing and a 220A high battery charging current, compatible with lithium and lead-acid batteries. It also supports diesel generator input and battery-free operation for flexible energy use.
-
Key Specs & Visuals
-
-
Resúmenes
-
- 12,000W continuous output with 125% EPS peak capacity for high-demand applications.
- Supports 120V/240V split-phase systems for North American residential use.
- Dual MPPT (27A+27A) enables up to 150% PV oversizing for higher solar yield.
- Supports up to 220A battery charging current with lithium and lead-acid compatibility.
- 10ms UPS-level switching ensures seamless backup during grid outages.
- Soportes hasta 6 units in parallel for scalable power expansion.
- Includes CT-based zero export control and supports battery-free operation.
- Supports diesel generator input and heavy-duty 6HP motor loads.
- Equipped with touchscreen control and remote OTA upgrade capability.
- Complies with UL1741 standards for reliable US market operation.
Solicita un presupuesto
Descargar folleto
Ventajas principales
Alta potencia
12,000W continuous and 125% EPS peak capacity.
Strong Motor Capability
Supports up to 6HP inductive loads.
Advanced Solar Input
Dual MPPT with up to 150% PV oversizing.
High Charging Performance
Supports up to 220A battery charging current.
Escalabilidad del sistema
Soportes hasta 6 units in parallel operation.
Smart & Certified System
CT zero export, Actualizaciones OTA, UL1741 compliant.
Especificaciones del producto
Modo AC
| Tensión de entrada nominal | 120V (L1/N, L2/N) / 240Vac (L1/L2) | Rango de tensión-fase de entrada | (85Vac ~ 140Vac) ±2% |
| Frecuencia | 50Hz / 60Hz (Detección automática) | Rango de frecuencias | 47±0,3Hz ~ 55±0,3Hz (50 Hz); 57±0,3Hz ~ 65±0,3Hz (60Hz) |
| Sobrecarga / Protección contra cortocircuitos | Interruptor automático | Eficacia | >95% |
| Tiempo de conversión (Circunvalación & Inversor) | 10MS (Típico) | Max. AC Input Current | 2 pole, 185A / 185A (L1/L2) |
Ver documento completo
Aplicación
This 12kW split-phase hybrid inverter is designed for high-capacity residential and light commercial solar-plus-storage systems in North America. Proporciona alimentación de respaldo fiable, supports heavy inductive loads, enables zero-export grid compliance, and allows flexible configurations including parallel expansion, generator hybrid operation, and battery-free energy management.
